Silverstone

Silverstone is the most powerful tool yet for examining the retina. The only ultra-widefield retinal imaging device with integrated, UWF-guided swept source OCT, Silverstone produces a 200° single-capture optomap image in less than ½ second and enables guided OCT scanning across the retina and into the far periphery. Imaging modalities and image viewing options are detailed below.

Silverstone

Silverstone OCT

Silverstone, the most powerful tool yet for examining the retina, is the only ultra-widefield imaging device with integrated swept-source OCT.  Silverstone produces a 200° single-capture retinal image of unrivaled clarity in less than ½ second and enables optomap-guided OCT scanning across the retina and into the far periphery.

Silverstone offers the following benefits:

  • UWF with integrated swept-source OCT, facilitates detailed examination of the retina-vitreous to sclera
  • UWF-guided, swept-source OCT, images pathology anywhere on the optomap
  • 1050 nm OCT light source, provides deeper tissue penetration for clear, detailed choroidal imaging
  • 3-in-1 Color Depth ImagingTM provides important clinical data from the retinal surface through the choroid

Specifications

Image Modalities

optomap color and optomap plus (red and green laser):
   Color composite
   Sensory Red-free
   Choroidal
optomap af (green laser): autofluorescence
optomap fa (blue laser): fluorescein angiography
optomap icg (infra-red): indocyanine green angiography
Swept Source Optical Coherence Tomography (OCT)

Resolution

optomap plus: 14 μm
opto
map: 20 μm

Wavelengths

Red laser: 635 nm
Green laser: 532 nm (for af )
Blue laser: 488 nm (for fa)
Infra-red: 802 nm (for icg)

Exposure Time

Less than 0.4 seconds

OCT Imaging

Signal Type: Optical scattering from tissue
Signal Source: Swept source OCT, Wavelength 1050 nm
Optical Power: Laser safety Class-1 following IEC/en60825-1:2014(2007)
Axial Resolution: <7 micron
Transverse Resolution: <20 micron (in tissue)
Scanners: Galavanometric with x, y pair
Scan Depth: Up to 2.5mm

OCT Scan Characteristics

Swept Source OCT
A-Scan rate up to 100k cycles/s

OCT Scan Types

Line Scan
Volume Scan
High Density Scan

Footprint

Width: 540 mm/22 inches
Depth: 570 mm/23 inches (including chin rest)
Height: 683-707 mm/27-28 inches
